lev Compact Mobile. Light - 10-12 kg Simple stone installation Information carrier - SD card CustomGraphs software Resolution 90-125 DPI High speed and image accuracy Number of halftones - 256 gradations Battery operation over 2 hours Warranty 1 year Post-warranty service Machine assembly: Machine "Lev" assembled (frame, control unit, shock mechanism) Power supply 220V / 12V (24V) 4 Ah SD card with CustomGraphs software and image library Diamond needle - 2 pieces. Wrench 5.5 x 7 Contact: Whatsapp 8-922-295-85-56
Technical specifications: 1. Cutting cable diameter-жу8-жу11mm 2. Cutting cable length-19300mm 3. Linear speed - (0-40) m/s 4. The total capacity is 19.94 kW. 5. Power of the main engine - 11 kW 6. Cutting in height - 1800 mm 7. Maximum cutting size (DxxV) - 3600*2000*1800 mm 8. Maximum weight of the block - 50 tons 9. Performance-(3m2/hour(marble)/2m2/hour(granite)) 10. External dimensions (DxShxV) - 8800x6800x4800 mm. 11. An approximate weight of 10,500 kg. Additional option rotating table 360 degrees, carrying capacity of 50 tons, control with a touchscreen, interpolated into the CNC machine
Technical specifications: 1. The diameter of the disc is а350-а400-а600-F800 mm. 2. Driver motor - 15/18.5 kW. 3. Table size (DxSh) - 3200x2000 mm. 4. Table rise - 0-85° 5. Rotation of the table - 90° 6. The maximum size of the slab (DxxV) is 3200x2000x300 mm. 7. External dimensions (DxShxV) - 6000x5000x2800 mm. 8. Water consumption - 4 m3. 9. Approximate weight of 6,000 kg.
The OSC-H1200 stone cutting machine is designed for sawing stone and other materials. A feature of this machine is that the processed material lies on the desktop, and the cutting circle moves along the guides. The machine has high accuracy, allows cutting at an angle of up to 45 degrees. The cooling of the disc is carried out by supplying water to the working area using a water pump. The length of the cut is 1.2 meters, the depth of the cut is 70-125 mm depending on the size of the disk. The electric motor is equipped with protection against overheating. Additional equipment allows you to process large-sized blanks Model: OSC-H1200L Power, kW: 2.2 Voltage, B: 220/380V Diameter saw, mm: 250-400 The angle of rotation of the disc: 0-45 degrees; Maximum length of cut, mm: 1200 Maximum depth of cut, mm: 70-125 Speed without load, rpm: 2800-3400 Application: granite, marble, porcelain, tile Weight, kg: 185 Dimensions, mm: 1730x810x360
The company "ALMAZPRO" offers to order from China a new 10-channel machine Hualong HLMW-10U Technical specifications: Maximum width/height of the saw: 3600/2150 mm Standard thickness of slabs: 20.5-96.5 mm Maximum desktop load: 40,000 kg Perlin diameter: 7.3 mm Length of ropes: 20,000 mm Maximum tension of ropes: 220-260 kg Rope speed: 20-35 m/s Water consumption: 250 l/min Engine power: 55 kW Total weight: 23,000 kg General dimensions: 10700×6800×2600 mm The total cost of the machine is 1,526,395.27 yuan, including VAT 20% Total delivery time from the factory in China to St. Petersburg, including production - 6 months from the date of receipt of prepayment. In addition - service for start-up and training on the machine ALMAZPRO has been supplying tools and industrial equipment for working with stone from Europe and China since 2016. We cooperate only with reliable and time-tested manufacturers who guarantee high quality of their products.
Company "ALMAZPRO" offers to order from China a new cable machine Xinda SHXJ1800 I Technical specifications: Diamond rope diameter: 8.0 - 11.0 mm Diamond rope length: 19300 mm Desktop size: 1800*2500 mm Linear speed (m/s): 0 - 40 Height of cable lift: 1900mm Desktop load capacity: 30,000 kg Maximum size of the workpiece: 3600*2500\.*1800 mm Production efficiency: 1-3 m2/h (marble) 0.5-2 m3/h (granite) Overall dimensions (DhShV): 8800*6800\*4750 mm Weight: 9,000 kg The total cost of the machine is 453,500 yuan, including VAT 20% The total delivery time from the factory in China to St. Petersburg, including production - 5 months. ALMAZPRO has been supplying tools and industrial equipment for working with stone from Europe and China since 2016. We cooperate only with reliable and time-tested manufacturers who guarantee high quality of their products.
Puerto Why is the WaterJet module installed on a 5-axis machine? - Of course, in terms of operating the machine as a typical “five-sevic” or a full-fledged WaterJet, this does not make much sense. Why? A lot of "buts", and the whole thing is in the use of the old type of water pump - injection - no efficiency or constant operation of engines, wear and tear, electricity consumption. - But the task for this was still – in some types of products you need a quick trimming of sharp corners and other subtle moments as part of the overall work. For this purpose, a cutter or an additional spindle is often used now. Of course, it is relatively cheap, but it is done slowly and there are serious limitations. As a result, as soon as it became possible to create a clear and effective SERVO pump for the rapid full inclusion of WaterJet, then it made sense to install this module on a 5-axis machine. Now hydraulic cutter has become a full-fledged, operational and understandable assistant in complex works with flat parts. This was done with the SawJet Orbit A5 from AitalMac. If you have additional questions about the topic of tools and equipment, feel free to contact: Write to WhatsApp (https://wa.me/+79262262638) +7 (926) 226-26-38 zakaz@almir.com
Automatic machine with electric drive, designed for rusting (paperboard) of any type of stone. The machine is equipped with a conveyor belt with programmable speed and an additional brush device to remove the remains of the split remaining on the surface. Sizes can vary depending on the type stones within the values specified below. Due to its strong design and ease of use This model is ideal for constant and intensive work associated with the processing of any type of stone. After welding, the carpentry parts of the Steinex machine are grinded on a CNC waste machine. Scattering provides an ideal fit in the assembly places of other components (split cylinder, blades, prismatics) guides, etc.).
